Finger Capacity |
4,000 |
Face Capacity |
2,000 (1:N) / 4,000 (1:1) |
Card Capacity |
10,000 |
Transactions Capacity |
1,00,000 |
User Photos |
4,000 |
Event Photos |
2,000 |
Communication |
TCP/IP, RS485,(For Slave Reader), USB Host, Wiegand |
|
Input / Output, Security Relay Box |
Hardware |
1.2GHz Dual Core CPU,Memory 128MB RAM / 256MB Flash, |
|
SilkID Fingerprint Sensor, 2,8 Inches TFT-LCD |
|
Touch Screen, 125KHz EM Reader / Mifare (Optional), |
|
Hi-Fi Voice & Indicator,Tamper Switch Alarm, Dual IR Camera |
Standard Functions |
Access Levels / Groups / Holidays , DST / |
|
Bell Schedule, Duress Mode, Anti-Passback, |
|
Record Query, Custom Wallpaper & Screen Saver |
Special Functions |
Multiple Biometric Verification Modes, Alive |
|
Finger Detection, Event Snapshot, User Photo |
Access Control Interface |
Lock Relay Output, Alarm Output / Auxiliary Input, |
|
Exit Button / Door Sensor, Doorbell Output |
Compatibility |
Wiegand Slave Reader, RS485 FP Slave Reader, |
|
BioSecurity Software |
Working Temperature |
-10 °C ~ 50 °C |
Dimensions |
190.8 × 85 × 103 mm |
Algorithm |
Face v7.0 & Finger v10.0 Algorithms |
Power |
Operating Voltage 12V DC, Current Draw < 500 mA |
