| Basic |
Maximum length of Boom |
6M (Optional 3m/4m) |
|
Arm material |
Aluminium |
| Boom Barrier |
Time for Up/down |
2s (for 1 – 3 m), 6s (for 4 – 6m) |
|
Input control signal |
Dry Contact |
|
Ingress protection Degree |
IP54 |
| Features |
Input Interface for |
1. Photocell |
|
|
2. Air switch |
|
|
3. Loop detector(Optional) |
|
Output interface for |
Lamp (Optional) |
|
Optional Interface |
Access control panel, |
|
|
Standalone Access Control, Control button (eg: X990) |
|
Remote Control |
Upto 25 meters |
|
Mode |
Automatic/Manual |
|
Incorporated control panel with |
3 push buttons (stop/up/Down) to control the motor |
|
Bumping bounce back |
Yes |
|
Auto closing time |
1 – 80s |
| General Specification |
SMPS – Input |
AC 220V / 110V, 50Hz / 60Hz |
|
Motor power |
90W, 220V AC |
|
Dimension(mm) |
268 X 348 X 1050 |
|
Operating Temprature |
-20oC to +50oC |
