| Basic |
Model No |
4 MP PTZ |
|
Type |
High speed Dome PTZ |
|
Sensor |
1/3″ CMOS Sensor |
|
Effective Pixels |
2512×1520 |
|
Minimum illumination |
color: 0.05 Lux/F1.4, B/W:0Lux (IR on) |
|
S/N Ratio |
>50dB |
|
Supports AGC, BLC, 3DNR, AWB |
|
|
Electronic Shutter Speed |
Auto/ Manual 1/50 – 1/10000 |
|
IR Range |
60m |
| Pan&Tilt |
Pan Range |
360 Endless |
|
Pan Speed |
2.5°- 180° |
|
Tilt Range |
0-90° |
|
Preset |
128 |
|
Patrol |
6 Patrol (16 preset each) |
| Lens |
Focal length |
2.8 – 12mm |
|
Max Aperture |
F1.4 |
|
Focus Control |
Auto |
|
Angle of view |
H:107°(Wide)-35°(Tele) , V:61°(Wide)-20°(Tele) |
|
Lens |
Motorized/Auto Iris(DC) |
| Video |
Video Compression |
H.264 High Profile/JPEG Snapshot |
|
Resolution |
4M/3M/1080P/720P |
|
Video Bit rate |
1024Kbps – 8092kbps |
|
Video Frame Rate |
30fps@ 4MP |
| Audio |
Audio |
Yes |
|
Audio compression |
ADPCM |
|
Audio interface |
1 Ch RCA |
|
Ethernet |
RJ-45 (10/100 Base-T) |
|
Protocol |
IPV4, HTTP, SSl, TCP/IP, UDP,UPnP, |
|
|
ICMP,IGMP,SNMP,RTSP,RTP,SMTP,NTP,DHCP,DNS, |
|
|
PPPOE,DDNS,FTP,IP filter, QoS, Cloud |
|
ONVIF |
ONVIF 2.1 |
|
Mobile App |
Iphone, windows, Android |
|
Browser |
IE, chrome, Firefox |
|
Max User Access |
12 |
| Power Supply |
Power Supply |
DC12V, 2A |
|
POE |
POE(802.3af) |
|
Power Consumption |
<20W |
|
Temperature |
-10oC to +55oC |
|
Humidity |
10% to 90% |
|
Ingress Protection |
IP66 |
|
Dimension |
Φ136×201 mm |
|
Weight |
1.68 Kg |
