| Basic |
Sensor |
1/2.7” 4.0M CMOS |
|
Lux |
0.05Lux@F1.2 (Color Mode); 0.01 |
|
|
Lux@F1.2(B&W); 0Lux (IR on) |
|
WDR Range |
96dB |
|
SN Ratio |
≥41dB (AGC OFF) |
|
AGC |
AUTO/MANUAL |
|
WB |
AUTO, INDOOR, OUTDOOR, sodium lamp |
|
|
Mode, MANUAL |
|
Noise Reduction |
2DNR, 3DNR |
|
Exposure Mode |
Program mode (customizable shutter interval), |
|
|
shutter mode (1/5 – 1 / 20,000s), slow shutter mode |
|
Compression |
H.264 Main profile / M-JPEG |
|
Max Pixiel |
2592×1520@60fps |
|
Output Rate |
Constant Bit Rate (CBR) or variable |
|
|
bit rate (VBR), stream settable |
|
Range |
32Kbps ~ 10Mbps |
|
Number of Visits |
Main stream 3 users, sub stream 6 users |
|
Network protocol |
TCP/IP, HTTP, NTP, IGMP, DHCP, UDP, SMTP |
|
|
RTP, RTSP, ARP, DDNS, DNS, HTTPS, P2P |
|
ONVIF protocol |
ONVIF2.4 |
|
Compatibility |
Support 3rd party |
|
Mobile Remote |
Android, IOS |
|
Internet Port |
1 port 10 / 100Base T Ethernet, RJ45 port |
|
Power |
12V DC, 2A |
|
Working Temperature |
-20°C to 60°C |
|
Working Humidity |
0% to 90% RH (non-condensing) |
